Double Toggle Push Button Insert for Downstream Electronics. Contacts at the Top and Bottom. White.
€53.32
Available in 14 days, delivery time 2-5 days
Product information "Double Toggle Push Button Insert for Downstream Electronics. Contacts at the Top and Bottom. White."
Double Toggle Momentary Switch, Spring-Return
This high-quality double toggle momentary switch from VECTIS is designed for applications where a circuit only needs to be closed briefly — for example, to control shutters, blinds or other suitable control systems.
Important: this is not a latching switch.
The toggle levers do not remain permanently in position. As soon as a toggle lever is released, it automatically springs back to its original position. The circuit is only closed for as long as one of the toggle levers is held down.
The mechanism is manufactured by VECTIS in the EU and is compatible with suitable VECTIS front plates. The precise workmanship and metal toggle levers give every operation a pleasantly premium feel of quality, stability and luxury.
Technical specifications
250 V
10 AX
Protection rating: IP20
For installation in EU wall boxes
Installation depth: 33 mm
Connection for flexible or solid wires with a cross-section of 1.5 to 2.5 mm²
In accordance with EN 60669-1
Scope of delivery
Mechanism with two toggle levers
Please note
The matching VECTIS front plate is not included and must be ordered separately.
